Home Mountain Bike
Ninety Six XT 2025

Ninety Six XT 2025

$ 65.00

$ 251.00

Unavailable
Ninety Six XT 2025

Ninety Six XT 2025

$ 65.00

$ 251.00

Size:
  • SM
  • MD
  • LG
  • XL
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

There used to be a time when you had to choose between trail bike performance and cross-country race ready weight. Not any more. Say hello to the NINETY-SIX XT. It builds on the speedy genes of our short travel race winner with a CF4 carbon frame and adds a whole new layer of capability thanks to a longer travel 120 mm Fox 34 SL Performance fork paired to 100 mm out back. Add in fast rolling tyres, a long travel dropper post and a super smooth Shimano XT drivetrain and brakes and you're ready to rock.

The NINETY-SIX is the latest incarnation of our former World Cup proven XC and marathon machine. It inherits the forward-surging race genes of the old NINETY-SIX and combines it with a new readiness and ability to tackle todays demanding XC and marathon courses. The carbon fibre frame platform and P-FLEX suspension is the perfect basis for a fun-packed, fast and trail loving short travel full suspension machine that helps define what a modern cross-country race bike should be. It's able to take on the rougher than ever world-class race tracks as well as the trail riders who want hyper-speed climbing with the ability to descend like never before.

Specification
FRAMENINETY-SIX CF4 III; 100 STR; MAT carbon; 29x2.35" max. WHS; 148x12 AST; BSA BBR
SHOCKFox Float SL Performance Elite; Large Volume aircan; 3 Pos PTL remote lockout
FORKFox 34 Float SC Performance; Air; 120 STR; Tapered; 3 Pos Remote lockout; 44mm fork offset
BRAKE-FShimano XT M8100; 2 piston
BRAKE-RShimano XT M8110; 2 piston
ROTOR-FShimano RT54; 180mm
ROTOR-RShimano RT54; 160mm
CHAINKMC X12
CHAINGUARD
CRANKSETShimano XT; 32 ATC
CRANK LENGTH170 mm-S, 175 mm-M up
BOTTOM BRACKETShimano BB-MT-501; 24mm
DERAILLEUR-FRONT
DERAILLEUR-REARShimano XT M8100 Shadow ; SGS
CASSETTEShimano XT; 10-51 ATC; 12 GER
GRIPSRock Shox TwistLoc grip
HANDLEBARMERIDA EXPERT CC; MAT aluminium; 760 WHB; flat
STEMMERIDA TEAM CC III; MAT aluminium; 31.8 DSH; -6 ASD; incl. MERIDA SMART MOUNT
STEM SIZES:60 mm, M/L/XL:70 mm
HEADSETAcros ICR MERIDA INTEGRATED neck; Upper and lower IPS sealing
HUB-FShimano XT; 110x15 WHF; 32 SPH; Centerlock
HUB-RShimano XT; 148x12 WHR, 32 SPH; Centerlock
AXLE-F
AXLE-RMERIDA EXPERT TR; including removeable lever, 6/4mm allen key
RIMMERIDA EXPERT CC II; 25 IWR; MAT aluminium; Tubeless ready (tubeless tape and valves not included)
SADDLEMERIDA EXPERT SL; V-mount; incl. MERIDA minitool
SEAT CLAMPMERIDA EXPERT
SEATPOSTMERIDA TEAM TR SL; 30.9 DSP; 0 SSB; 150 SPT
SHIFTER-FRONTJD-FL lever
SHIFTER-REARShimano XT M8100; Multi Release
SPOKESDouble Butted Black stainless
TIRE-FMaxxis Rekon Race; 29x2.4" WT; tubeless ready; 3C MaxxTerra EXO
TIRE-RMaxxis Rekon Race; 29x2.25"; fold; TR EXO 120 TPI

Geometry

SMMDLGXL
Tyre Sizes29"29"29"29"
ST seat tube [mm]400440470500
TT top tube [mm]576596619643
CS chain stay length [mm]435435435435
HTA head tube angle []68.568.568.568.5
STA seat tube angle []76.576.57676
BD bottom bracket drop [mm]45454545
HT head tube [mm]9595105115
FL fork length [mm]503503503503
R reach [mm]433453473493
S stack [mm]585585595604
WB wheel base [mm]1126114611691193
SH stand over height [mm]730731736738
Size
FRAME SIZEBODY HEIGHT
S< 173 cm
M167 - 183 cm
L177 - 190 cm
XL> 187 cm
