Hydroforming aluminium frame with fully integrated C.I.S. cable routing and smartly attached tool bag

130 mm travel with new F.O.L.D. kinematics optimized for more progression: FOX Float 34 Rhythm suspension fork and FOX Float DPS rear shock

Reliable und precise Shimano XT components and perfect XT 4/2-piston brakes mix

Aluminium frame with tool bag

130 mm FOX Float 34 Rhythm fork & Float DPS shock

Shimano XT components

• Brake
  • 180
• Frame size
  • S,M,L,XL
  • 39,42,45,48
• Groupset
  • Shimano Deore XT
• Max total weight
  • 110 kg
• Frame
  • 7005 Aluminum, 130 mm F.O.L.D. kinematic, BSA BB, ISCG 05, 148x12 thru axle, internal cable routing, Post Mount 180 mm
• Fork
  • FOX 34 Float Rhythm 29, Grip Remote, 110x15 mm, 44 mm rake
• Handlebar
  • Aluminium 35 mm, riserbar 11mm, 760mm
• Saddle
  • Focus Trail SL
• Seat post
  • Post Modern dropper post PM-171, 31.6 mm
• Stem
  • FOCUS C.I.S. integrated, 50 mm, 0 degree, 35 mm, aluminium
• Brakes
  • Shimano XT M8120 4-piston (front) / M8100 2-piston (rear)
• Crank set
  • Shimano Deore XT FC-M8100, Hollowtech II
• Sprocket
  • Shimano Deore M6100, 12-speed
• Transmission
  • front: 32, rear:10-51
• Wheel rims
  • Rodi TRYP25, with eyelets
• Brake lever
  • Shimano XT M8120, 4 piston
• Color
  • mineralgreen
• Travel
  • 130 mm
• Hub
  • Novatec D041, 15x110 mm
  • Novatec D462 Disc, 12x148 mm
• Grip
  • BBB Cobra BHG-96
• Rear derailleur
  • Shimano Deore XT M8100, 12-speed
• Tire
  • Maxxis Dissector 2.4
  • Maxxis Rekon 2.4
• Bottom bracket
  • BSA
• Shift/brake lever
  • Shimano XT M8120, 4 piston
  • Shimano Deore XT M8100, 12-speed
• Spoke
  • Niro, black
• Chain
  • Shimano Deore CN-M6100, 12-speed
