Experience the ultimate combination of speed and comfort with the Trek Madone SLR 7 AXS Gen 8. Its 900 Series OCLV Carbon frame is not only aerodynamic but also incredibly lightweight for effortless climbs. With a SRAM Force AXS D2 drivetrain with power meter, Trek Aero RSL one-piece carbon bar/stem and Aeolus Pro 51 Carbon Wheels, this bike is built to win races.
Why it is so amazing
- The Revolutionary Full System Foil aero tube shapes redefine what fast looks like and help optimise aerodynamics around the whole bike
- It is made with Trek's highest-level 900 Series OCLV carbon, which is crazy light and stiff where you need the power, and compliant where you are looking for comfort.
- Aeolus Carbon Wheels keep the weight down and performance up, so you can dominate climbs and soar down descents.
- It comes with clean, wireless shifting that's ultra-precise and programmable, thanks to SRAM Force AXS D2 and a power meter for watching your output and getting the most from your ride.
- RSL Aero Bottles and Cages makes everything on the bike faster to give you even more aerodynamic gains.
- A new Blendr system on the bar/stem - makes it easy to add and remove a daytime running light.
| Frame | 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle |
|---|---|
| Fork |
| Weight | ML - 7.43 kg / 16.39 lbs (with TLR sealant, no tubes, no bottles/cages) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Battery | SRAM eTap battery pack (with charger) |
|---|
| Shifter | SRAM Force AXS D2, 12-speed |
|---|---|
| Front derailleur | SRAM Force AXS D2, braze-on |
| Rear derailleur | SRAM Force AXS D2, 36T max cog |
| *Crank | Size:XS, S SRAM Force AXS D2, power meter, 48/35, DUB, 165 mm length |
| Size:M SRAM Force AXS D2, power meter, 48/35, DUB, 170 mm length | |
| Size:ML, L SRAM Force AXS D2, power meter, 48/35, DUB, 172.5 mm length | |
| Size:XL SRAM Force AXS D2, power meter, 48/35, DUB, 175 mm length | |
| Bottom bracket | SRAM DUB, T47 threaded, internal bearing |
| Cassette | SRAM Force XG-1270, 10-33, 12 speed |
| Chain | SRAM Force, 12-speed |
| Max. chainring size | 1x: 54T, 2x: 56/43 |
| Wheel front | Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle |
|---|---|
| Wheel rear | |
| Skewer front | |
| Skewer rear | |
| Tyre | Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Max tyre size | 32 mm (as measured, see manual for details) |
| *Saddle | Size:XS, S |
|---|---|
| Size:M, ML, L, XL | |
| *Seatpost | Size:XS, S, M |
| Size:ML, L, XL | |
| *Handlebar/stem (integrated) | Size:XS |
| Size:S | |
| Size:M | |
| Size:ML, L | |
| Size:XL | |
| Brake rotor | SRAM CentreLine X, CentreLock, round edge, 160 mm |
| Rotor size | Max brake rotor sizes: 180 mm front, 160 mm rear |
Sizing
| Size | Rider Height | Inseam |
|---|---|---|
| XS | 143 - 158 cm 4'8" - 5'2" | 67 - 74 cm 26" - 29" |
| S | 158 - 162 cm 5'2" - 5'4" | 74 - 76 cm 29" - 30" |
| M | 162 - 173 cm 5'4" - 5'8" | 76 - 81 cm 30" - 32" |
| ML | 173 - 179 cm 5'8" - 5'10" | 81 - 84 cm 32" - 33" |
| L | 179 - 188 cm 5'10" - 6'2" | 84 - 88 cm 33" - 35" |
| XL | 188 - 213 cm 6'2" - 7'0" | 88 - 100 cm 35" - 39" |
Geometry
All measurements provided in cm unless otherwise stated.
| Frame size letter | Wheel size | A Seat tube | B Seat tube angle | C Head tube length | D Head angle | E Effective top tube | G Bottom bracket drop | H Chainstay length | I Offset | J Trail | K Wheelbase | L Standover | M Frame reach | N Frame stack | Saddle rail height min (w/short mast) | Saddle rail height max (w/short mast) | Saddle rail height min (w/tall mast) | Saddle rail height max (w/tall mast) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 700c | 40.4 | 73.8 | 10.0 | 71.6 | 51.7 | 7.2 | 41.0 | 5.0 | 6.1 | 97.1 | 70.9 | 37.0 | 50.7 | 54.9 | 61.2 | 59.2 | 65.4 |
| S | 700c | 44.0 | 73.8 | 12.1 | 72.2 | 53.2 | 7.2 | 41.0 | 4.5 | 6.2 | 97.6 | 74.0 | 37.8 | 53.0 | 58.5 | 64.8 | 62.8 | 69.0 |
| M | 700c | 47.6 | 73.6 | 13.6 | 72.9 | 54.5 | 7.0 | 41.0 | 4.5 | 5.8 | 98.1 | 76.8 | 38.4 | 54.6 | 62.1 | 68.4 | 66.4 | 72.6 |
| ML | 700c | 51.2 | 73.4 | 15.0 | 73.5 | 55.7 | 7.0 | 41.0 | 4.0 | 5.9 | 98.0 | 79.4 | 38.9 | 56.2 | 65.7 | 72.0 | 70.0 | 76.2 |
| L | 700c | 54.8 | 73.4 | 17.2 | 73.8 | 56.8 | 6.8 | 41.1 | 4.0 | 5.7 | 99.0 | 82.5 | 39.4 | 58.2 | 69.3 | 75.6 | 73.6 | 79.8 |
| XL | 700c | 60.9 | 73.4 | 20.1 | 73.9 | 58.4 | 6.8 | 41.2 | 4.0 | 5.7 | 100.7 | 86.9 | 40.2 | 61.0 | 75.4 | 81.7 | 79.7 | 85.9 |
**** Trekreserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
