StumpJumper LTD Full Suspension 29" Mountain Bike

StumpJumper LTD Full Suspension 29" Mountain Bike

$ 57.58

$ 268.48

Unavailable
StumpJumper LTD Full Suspension 29" Mountain Bike

StumpJumper LTD Full Suspension 29" Mountain Bike

$ 57.58

$ 268.48

Color:
  • Grey
Size:
  • S1
  • S2
  • S3
  • S4
  • S5
  • S6
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Introducing the Specialized StumpJumper LTD Full Suspension 29" Mountain Bike the trail-blazing beast that's got your back from peak to valley! Calling it "The Ultimate Trail Bike" is no exaggeration; this two-wheeled wonder is here to rock your world.

Let's start with climbing - a breeze with the StumpJumper's ground-breaking suspension redesign and the feather-light frame, making uphill battles a thing of the past. It practically floats up those inclines!

So, if you're looking for a bike that's not just a ride but a trail-ripping, adventure-packed, party-on-wheels, the Specialized StumpJumper LTD is your perfect match. Prepare to conquer mountains, embrace gravity, and make memories that'll last a lifetime with this trail-blazing masterpiece.

Features:

  • THE TRAIL BENCHMARKWhen we set out to design the all-new Stumpjumper, we pursued some hefty goals. It had to excel on any kind of trail, for every style of rider. To achieve that, we went after serious weight reduction without sacrificing durability, a stiff, responsive chassis that still rides light and lively, geometry that improves everyones riding, and the best suspension kinematics we know how to design. Turns out, you can have your cake and eat it too with the new Stumpjumper.
  • THE SWEETEST 130MM OF TRAVEL YOULL EVER RIDEWe massaged the kinematics of the Stumpjumper suspension to bring out the very best all-round performance possible in a 130mm package. Countless hours of suspension lab development and field testing created a refined mid-travel ripper that eats big terrain like a gravity fed beast, handles like a dream everywhere, and climbs like it has a motor.
  • PROGRESSIVE GEOMETRYThe S-Sizing geometry of the new Stumpjumper hits the progressive sweet spot. Its long, low and slack, with a short offset fork and a steeper seat tube angle. These numbers combine to make your ride more stable, more carvealicious, more comfortable climbing, more better everywhere. With FlipChip adjustability youre able to further fine-tune your fit, ensuring that your new Stumpjumper performs flawlessly on whatever terrain you choose.
  • RIDER-FIRST ENGINEEREDRider-First Engineered frames use a size-specific approach to ride characteristics that ensures benchmark handling and flawless performance, regardless of frame or rider size. Whether youre a jump-happy grom riding an S1, or a DH-fiend giant in need of the lengthy S6, youll experience the same ride traits rail-sharp cornering and balanced front and rear stiffness at the lightest-possible weight, And by light, we mean real light: 2,250 grams (S-Works, S-3 size, with rear shock).
  • SWATWe introduced the SWAT door on the Stumpjumper in 2016, adding room IN your frame for those oh sh**t necessities like pumps and spare tubes, and immediately rendering jersey pockets redundant.

Specifications


Rims

Roval Traverse 29F/27.5R Alloy, 30mm inner width, hand-built, 2Bliss Ready

Front Hub

Roval, sealed cartridge bearings, 15x110mm spacing, 28h

Rear Hub

Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h

Rear Tire

Purgatory, GRID casing, GRIPTON T7 compound, 2Bliss Ready, 27.5x2.3"

Spokes

DT Swiss Competition Race

Front Tire

Butcher, GRID casing, GRIPTON T9 compound, 29x2.3"

Inner Tubes

Standard, Presta Valve

Handlebars

Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp

Grips

Deity Lockjaw

Saddle

Bridge Comp, Hollow Cr-mo rails, 155/143mm

Stem

Alloy Trail Stem, 35mm bar bore

Cassette

SRAM GX Eagle Transmission Cassette, 12spd, 10-52t

Chain

SRAM GX Eagle Transmission Flattop Chain

Crankset

SRAM GX Eagle Crankset, Alloy, Integrated Guard, 55mm Chainline, S1:165mm, S2-S5: 170mm, S6: 175mm

Rear Derailleur

SRAM GX Eagle Transmission Cassette, 12spd, 10-52t

Shift Levers

SRAM AXS POD Controller

Bottom Bracket

SRAM DUB, BSA 73mm Wide, Threaded

Chainrings

32T

Front Brake

SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm

Rear Brake

SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 180mm

Fork

RockShox Pike Ultimate, Charger 3 RC2 Damper w/Buttercups, 15x110mm axle, 44mm offset, 140mm of travel

Rear Shock

RockShox Deluxe Ultimate, Rx Trail Tune, 190x45

Frame

FACT 11m carbon chassis and rear-end, asymmetrical design, 29/27.5 Trail Geometry, SWAT Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel

Seat Binder

Alloy, 38.6mm

Geometry

S1S2S3S4S5S6
Crank Length165mm170mm170mm170mm170mm175mm
Handlebar Width780mm780mm780mm780mm780mm780mm
Stem Length40mm40mm40mm40mm50mm50mm
Saddle Width155mm155mm143mm143mm143mm143mm
Seatpost Length120mm150mm150mm180mm210mm210mm
Stack (Low BB)614mm613mm622mm632mm641mm650mm
Stack (High BB)610mm609mm618mm627mm636mm646mm
Reach (Low BB)410mm430mm450mm475mm500mm530mm
Reach (High BB)415mm435mm455mm480mm505mm535mm
Headtube Length95mm100mm110mm120mm130mm140mm
Headtube Angle (Low BB)656565656565
Headtube Angle (High BB)65.565.565.565.565.565.5
BB Height (Low BB)328mm333mm333mm333mm333mm333mm
BB Height (High BB)335mm340mm340mm340mm340mm340mm
BB Drop (Low BB)47mm42mm42mm42mm42mm42mm
BB Drop (High BB)40mm35mm35mm35mm35mm35mm
Trail (Low BB)126mm126mm126mm126mm126mm126mm
Trail (High BB)123mm123mm123mm123mm123mm123mm
Fork Length (full)550mm550mm550mm550mm550mm550mm
Fork Rake/Offset44mm44mm44mm44mm44mm44mm
Front Center724mm746mm770mm800mm829mm863mm
Chainstay Length432mm432mm432mm432mm442mm442mm
Wheelbase1152mm1175mm1200mm1228mm1268mm1302mm
Top-tube Length (horizontal)563mm583mm605mm632mm660mm692mm
Bike Standover Height730mm734mm744mm749mm757mm757mm
Seat Tube Length385mm385mm405mm425mm445mm465mm
Seat Tube Angle (Low BB)767676767676
Seat Tube Angle (High BB)76.576.576.576.576.576.5
Max Seatpost Insertion220mm220mm240mm260mm280mm300mm
Min Seatpost Insertion80mm80mm80mm80mm80mm80mm
