Description
Whether youre carving down a steep loam line, dropping in for an enduro stage, or heading into the backcountry for an all-day epic, this bike performs. With increased rearward axle path, idler, and the innovative VPSHPsuspension layout, this new design gives the Sight next level confidence and capability, up or down the mountain. With 160/150mm of travel, the 2025 Sight takes the best of the Range platform and has tightened it up into a light, pedal friendly, maneuverable, high-pivot package.
All Sight models also now include the One Up EDC lite tool to have you covered on the trail.
Specification
| FRAME | Carbon Frame, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned |
| FORK | RockShox Lyrik Select, Charger RC, DebonAir , 160mm, 44mm Offset |
| REAR SHOCK | RockShox Vivid 2 Select Air, 205x60mm TR |
| HEADSET | FSA No. 57 ZS, Sealed Bearing, Tapered 1-1/8" - 1.5", ( ZS44/28.6 | ZS56/40 ) |
| GRIPS | SDG Thrice, 135mm Length |
| HANDLE BAR | Norco 6061 Alloy, 800mm, 25mm Rise |
| STEM | Norco 6061 Alloy, 40mm Length, 35mm Clamp |
| SEAT POST | TranzX YS105, 34.9mm, 150 (S1) -170mm (S2) -200mm (S3,S4) -230mm (S5) |
| SADDLE | WTB Volt 250 Sport |
| FRONT BRAKE | Shimano Deore MT520 4-Piston, Metallic Pads |
| FRONT BRAKE ROTOR | Shimano RT-64, 200mm |
| REAR BRAKE | Shimano Deore MT520 4-Piston, Metallic Pads |
| REAR BRAKE ROTOR | Shimano RT-64, 180mm |
| BRAKE LEVERS | Shimano Deore MT520 4-Piston |
| SHIFTER REAR | Shimano Deore SL-M6100, 12sp |
| REAR DERAILLEUR | Shimano Deore RD-M6100, 12sp |
| CASSETTE | Shimano Deore CS-M6100-12, 10-51T, 12sp |
| CHAIN | Shimano Deore CN-M6100, 12sp |
| CRANKSET | Shimano Deore FC-MT6120-1, 32T, CL55, 165mm (S1,S2) -170mm (S3,S4,S5) |
| BOTTOM BRACKET | Shimano Sealed Bearing, BSA 73mm |
| FRONT HUB | Bear Pawls BMB-513, 15x110mm Boost, 32h, C-lock |
| REAR HUB | Shimano FH-MT510, 12x148mm Boost, Micro Spline, 32H, C-lock |
| SPOKES/NIPPLES | Stainless Steel |
| RIMS | Stans Flow D, 32H, F- 29", R-27,5", 29mm ID |
| FRONT TIRE | Maxxis Assegai, 3C MaxxGrip EXO , 29x2.5", Folding |
| REAR TIRE | Maxxis Minion DHR II, 3C Maxx Terra EXO , 27.5x2.4", Folding |
Geometry
| Travel (mm front/mm rear) | 29"/27.5" | 1160/150 | 2160/150 | 3160/150 | 4160/150 | 5160/150 |
| 29" | 1160/150 | 2160/150 | 3160/150 | 4160/150 | 5160/150 | |
| Reach | 29"/27.5" | 1422.5 | 2447.5 | 3472.5 | 4497.5 | 5522.5 |
| 29" | 1422.5 | 2447.5 | 3472.5 | 4497.5 | 5522.5 | |
| Stack | 29"/27.5" | 1618 | 2627 | 3636 | 4645 | 5654 |
| 29" | 1618 | 2627 | 3636 | 4645 | 5654 | |
| Head Tube Angle | 29"/27.5" | 164.0 | 264.0 | 364.0 | 464.0 | 564.0 |
| 29" | 164 | 264 | 364 | 464 | 564 | |
| Fork Offset | 29"/27.5" | 144 | 244 | 344 | 444 | 544 |
| 29" | 144 | 244 | 344 | 444 | 544 | |
| Seat Tube Length | 29"/27.5" | 1350 | 2370 | 3385 | 4430 | 5445 |
| 29" | 1350 | 2370 | 3385 | 4430 | 5445 | |
| Effective Seat Tube Angle | 29"/27.5" | 177.00 | 277.25 | 377.50 | 477.75 | 578.00 |
| 29" | 177 | 277.25 | 377.5 | 477.75 | 578 | |
| Rear Centre Length | 29"/27.5" | 1420 | 2424 | 3428 | 4432 | 5436 |
| 29" | 1426 | 2430 | 3434 | 4438 | 5442 | |
| Bottom Bracket Drop (Front/Rear) | 29"/27.5" | 125/4 | 225/4 | 325/4 | 425/4 | 525/4 |
| 29" | 125/25 | 225/25 | 325/25 | 425/25 | 525/25 | |
| Bottom Bracket Height | 29"/27.5" | 1353 | 2353 | 3353 | 4353 | 5353 |
| 29" | 1353 | 2353 | 3353 | 4353 | 5353 | |
| Horizontal Top Tube | 29"/27.5" | 1565 | 2589 | 3613 | 4637 | 5661 |
| 29" | 1565 | 2589 | 3613 | 4637 | 5661 | |
| Wheelbase | 29"/27.5" | 11181 | 21214 | 31247 | 41281 | 51314 |
| 29" | 11186 | 21219 | 31253 | 41286 | 51319 | |
| Standover | 29"/27.5" | 1673 | 2679 | 3685 | 4708 | 5720 |
| 29" | 1673 | 2679 | 3685 | 4708 | 5720 | |
| Head Tube Length | 29"/27.5" | 1105 | 2115 | 3125 | 4135 | 5145 |
| 29" | 1105 | 2115 | 3125 | 4135 | 5145 | |
| Trail | 29"/27.5" | 1135 | 2135 | 3135 | 4135 | 5135 |
| 29" | 1135 | 2135 | 3135 | 4135 | 5135 | |
| Recommended Seatpost Drop | 29"/27.5" | 1150 | 2170 | 3200 | 4200 | 5230 |
| 29" | 1150 | 2170 | 3200 | 4200 | 5230 | |
| Maximum Post Insertion | 29"/27.5" | 1250 | 2270 | 3300 | 4300 | 5330 |
| 29" | 1250 | 2270 | 3300 | 4300 | 5330 | |
| Stem Length | 29"/27.5" | 140 | 240 | 340 | 440 | 540 |
| 29" | 140 | 240 | 340 | 440 | 540 | |
| Crank Length | 29"/27.5" | 1170 | 2170 | 3170 | 4170 | 5170 |
| 29" | 1170 | 2170 | 3170 | 4170 | 5170 | |
| Tire Size | 29"/27.5" | 12.35" 2.6" | 22.35" 2.6" | 32.35" 2.6" | 42.35" 2.6" | 52.35" 2.6" |
| 29" | 12.35" 2.6" | 22.35" 2.6" | 32.35" 2.6" | 42.35" 2.6" | 52.35" 2.6" | |
| Water Bottle Compatible | 29"/27.5" | 11 x 750 mL | 21 x 750 mL | 31 x 750 mL | 41 x 750 mL | 51 x 750 mL |
| 29" | 11 x 750 mL | 21 x 750 mL | 31 x 750 mL | 41 x 750 mL | 51 x 750 mL |
