S-Works Turbo Levo SL Carbon 2023

S-Works Turbo Levo SL Carbon 2023

$ 63.71

$ 279.28

Unavailable
S-Works Turbo Levo SL Carbon 2023

S-Works Turbo Levo SL Carbon 2023

$ 63.71

$ 279.28

Size:
  • S1
  • S2
  • S3
  • S4
  • S5
  • S6
Colour:
  • Rusted Red
  • Black
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

The Levo SL delivers unmatched ride quality and capability, amplified. For the trail rider who craves serpentine singletrack, sending it skyward, and lives for advancing your skills and fitness. Meet your new bike, the Levo SL. Youll be blown away by its unmatched combination of flawless handling, capability, and 2 X You amplification that gives you the Power to Ride More Trails. Compare it to anything out there, with a motor or without, and we know youll agree Levo SL is THE ULTIMATE TRAIL BIKE.

ITS ALL ABOUT THE RIDE When everything works just right a bike disappears when you ride it. We stripped away the mass to keep the Levo SL lean and responsive. Its tough enough to withstand heavy abuse, but light enough to nail big moves. Its dialed geometry, kinematics, and shock tuning leave nothing desired.

THE FRAME OF REFERENCE Everything starts here. Lively, precise ride feel. Strategic carbon fiber layup provides super-responsive chassis stiffness. We tuned the entire chassisfront end, rear end, and the link that unifies themas a single unit to minimize lateral flex under pedaling to harness every bit of pedal force.

GEOMETRY OF CONTROL The cockpit centers you in the bike, optimizing traction and corner control. The low bottom bracket, slack headtube angle, and reduced fork offset keep things stable in the rough while giving you the freedom to destroy the turns. The head angle can be personalized to, 63, 64.25, and 65.5 degrees.

LESS IS MORE The Levo SL is greyhound lean and telepathically responsive. Its curated component selection is light, yet capablefor true trail riding. Put it all together and you get the benefits of amplification along with benchmark handling.

MIXED WHEEL A 29 front wheel ensures stability and surefooted performance in the most hectic terrain, while a 27.5 rear wheel allows for a compact chainstay and super responsive behavior. If you prefer the rolling and traction benefits of a 29 rear wheel, just flip the pivot link chip and mount the big wheel.

TURBO OPERATING SYSTEM Our seamlessly-integrated operating system delivers unmatched performance across torque, range, ride feel, ride quality, power, reliability, and rider experience. Its the invisible hand that enables you to do more, know more, go farther, feel stronger, and have more fun.

SPECIALIZED SL 1.2 MOTOR The all new Specialized SL 1.2 motor is whisper quiet, boasts unmatched smoothness, delivers 43% more torque (50Nm), and 33% more power (320 Watts) than its predecessor. Resulting in 2x You performance; its you pedaling, but a side of you only a Levo can bring out.

GO DEEP RANGE Levo SL features a premium, high quality, and seamlessly integrated 320Wh battery pack. Combined with the efficient motor, youre set up for long, epic rides of up to 5 hours (in Eco Mode). For longer rides, just slide our 160 Wh Range Extender (sold separately) into your bottle cagefor 50% more range.

MASTERMIND TCU Our most advanced and intuitive e-bike control unit. Connecting the bike, the Turbo OS, the Mission Control App as well as the rider, all in a protected and easily visible display. MasterMind TCU enables over-the-air updates so your bike will get even better over time. With MicroTune fine-tuning power output levels in real time is at your fingertips, optimizing range management and performance.

MISSION CONTROL APP The Levo SL integrates fully with our Mission Control App and lets you personalize your motor characteristics with MicroTune, Support, and Peak Power. You can say goodbye to range anxiety with Smart Control, and even thwart would-be thieves with Turbo System Lock.

  • All new carbon frame, comes in mixed wheel configuration (compatible to 29 rear with no extra parts needed.) New kinematic with flatter leverage curve which provides more support and playfulness off the top, but plenty of control in rougher conditions. The headtube angle and bottom bracket height are both adjustable.
  • Worried about running out of power? No problem. Turbo Levo SL eats up big miles and long days. And if youre looking for even more miles, our included range extender boosts your range by another 50 percent. On top of all that, our Mission Control App can handle battery management automatically, ensuring your battery will last as long as you need it to.
  • New SRAM XX Eagle transmission
  • New SRAM Code Stealth Ultimate brakes
Specification
FRAMESET
Frame
All new Levo SL SW Frame, Fact 11m carbon, carbon shock extension, 150mm travel, adjustable head angle, BB height, and compatible with 27.5 or 29" wheels.
Seat Binder
Alloy, 38.6mm
ACCESSORIES
SWAT
PROTECTOR, 3M MY22 LEVO SL GEN2 CHAINSTAY YOKE CARBON_ALLOY 0.36MM MYLAR SATIN/GLOSS
SUSPENSION
Fork
Fox 36 Factory, 29", 44mm offset, Grip 2 damper, Kashima, 160mm
Rear Shock
S2-S6: Fox Float X Factory series, Kashima, 21x55mm, S1: Fox Float DPS Factory, Kashima, 210x50mm
COCKPIT
Saddle
Bridge, 155/143mm, Hollow Ti-rails
Grips
Deity Grips
Stem
Deity, 35.0mm
SeatPost
RockShox Reverb AXS, 30.9, 1X remote, (S1:100mm, S2: 125mm, S3: 150mm, S4-S6: 170mm)
Handlebars
Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm, 35.0mm
BRAKES
Rear Brake
BRAKE, MAGURA, 87270700282, REAR, MT7N MY17 R SHIFT MIX 3 2HC-W REACH W/TOOL 4 PSTN 90DEG GREY RING: SIL DISC TUBE 2.2 BLACK -25DEG 2000MM QM44(PM180-203) W/EASYROUTE X 1PC 2 SIDES MASTER COVER
Front Brake
Magura MT7, 4 piston caliper, Loic lever blade
DRIVETRAIN
Chainrings
New SL 1.2 spider, 104BCD w/SRAM 32t alloy ring
Shift Levers
SRAM Eagle AXS Rocker Paddle
Crankset
SRAM FC S996 MHL GEN2 WIDE C 165/170/175 NORNG/NOSPDR
Chain
SRAM XX1 Eagle
Rear Derailleur
SRAM XX1 Eagle AXS
Cassette
Sram XG-1299, 12-Speed, 10-52t
WHEELS
Front Tire
Butcher, GRID TRAIL casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON T7 compound, 2Bliss Ready, 27.5 x 2.3"
Inner Tubes
Standard, Presta Valve
Rims
Roval Traverse SL Carbon, 29 Front, 27.5 Rear, 30mm inner width, hand-built, 2Bliss Ready
Spokes
DT Swiss Competition Race
Rear Hub
Roval Traverse SL, DT Swiss Star Ratchet, 54t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing
Front Hub
Roval Traverse SL, sealed cartridge bearings, 15mm thru-axle, 110mm spacing
E-BIKE
Wiring Harness
Custom Specialized wiring harness
Charger
Custom charger, 48V System w/ SL system charger plug
Motor
New Specialized 1.2 SL Custom Rx Trail Tuned Motor
UI/Remote
Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, over-the-air updates, ANT /Bluetooth, w/Handlebar remote
Battery
Specialized SL1-320, fully integrated, 320Wh

Geometry
S1S2S3S4S5S6
Crank Length165165170170170175
Handlebar Width780780780780780780
Stem Length353535355050
Saddle Width155155143143143143
Seatpost Length100125150170170170
Stack609617626635645654
Reach405425445470495525
Head-Tube Length95100110120130140
Head-Tube Angle64.664.664.664.664.664.6
B-B Height343348348348348348
B-B Drop-34-29-29-29-29-29
Trail132132132132132132
Fork Length, Full560570570570570570
Fork Rake/Offset424242424242
Front-Center726752776806835869
Chain-Stay Length433432432432432432
Wheelbase115811841208123812671301
Top Tube Length, Horizontal560582604631659691
Bike Stand-Over Height727763766767773778
Seat-Tube Length385385405425445465
Seat-Tube Angle75.875.875.875.875.875.8
