Race circuits or Sunday Shreds, the Altitude has you covered. Purpose-built and race-proven, its the ultimate enduro weapon for demolishing steep trails and making every session faster. Sure, total enduro capability translates nicely to podiums. But it also means bigger and more committing weekend rides for the rest of us. With so much capability in your corner, it makes you want to push limits, climb faster, and get better.
Specifications
- FrameSMOOTHWALL Carbon. Full Sealed Cartridge Bearings. Press Fit BB. Internal Cable Routing. 2-Bolt ISCG05 Tabs. RIDE-9 Adjustable Geometry. 2 Position Axle. 160mm Travel. SMOOTHWALL Carbon Rear Triangle
- ForkFox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
- Front Travel170mm
- ShockFox Float X Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
- Rear Travel160mm
- HeadsetFSA Orbit NO.57E | Sealed Stainless 36x45 Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
- StemRocky Mountain 35 AM | 5 Rise | All Sizes = 40m
- HandlebarRocky Mountain AM | 780mmWidth | 38mm Rise | 9 Backsweep | 5 Upsweep | 35 Clamp
- GripsODI Elite Pro Lock On
- BrakesShimano XT Trail 4 Piston | Metal Pads | F: Shimano RT66 203mm | R: Shimano RT66 180mm
- ShiftersShimano SLX
- Rear DerailleurShimano XT
- Cranks & ChainringRace Face Aeffect Cinch | 32T | 24mm Spindle | 170mm Crank Length
- Bottom BracketFSA BB92 24mm
- CassetteShimano SLX 10-51T
- ChainShimano M7100
- Front HubRocky Mountain Sealed Boost 15mm
- Rear HubRace Face Trace Boost 148mm | 10 Engagement
- SpokesDT Swiss Competition 2.0/1.8/2.0
- RimsWTB ST Light i30 TCS 2.0 Tubeless | 32H | Tubeless Ready - Tape | Valves Incl
- TiresF: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra EXO Tubeless Ready |
- SeatpostRace Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote | SM = 125mm | MD = 150mm | LG - XL = 175mm
- SaddleWTB Volt Race 142
- Weight32.1 LBS|14.59 KGS
- NotesWe make every effort to ensure accuracy, but reserve the right to update specifications & prices without notification.
