Description
A summer blockbuster with an eye for adventure, the Rockhopper Comp lives for high action and fast-paced plot twists and features an all-new, Premium A1 Aluminum frame making its singletrack debut.
Roll the credits to discover an SR SunTour XCM fork with a custom two-way damping circuit, Stout wheelset, SRAM Level hydraulic stoppers and MicroSHIFTs wide-range 1x9 drivetrain and you have backup provided by a supporting cast thats all thriller and no filler, but will never leave you hanging.
- A heart of gold, presented in our lightweight yet durable Premium A1 Aluminum, the Rockhoppers butted aluminum frame features hydroformed top and downtubes in order to keep weight low and strength high, all while providing increased standover clearance, slick internal cable routing and dropper-post compatibility.
- With the goal of making sure that the Rockhopper offers both the best fit and best performance for every person, no matter their measure, weve paired each Rockhopper frame size with the optimal wheel size. The result is a Rockhopper to fit every rider and the assurance that every Rockhopper is rolling on the best-handling wheel for its frame size.
- Bringing our Rx Tune to Rockhopper for the very first time, the lockout-equipped SR Suntour XCM with custom Multi-Circuit damping brings size-specific travel and spring rates to the show in a performance thats sure to impress while also ensuring consistent geometry, handling and suspension performance, regardless of frame or wheel size.
- Beautifully beastly, SRAM Level hydraulic disc brakes pack a mean bite but deliver their power with a refined, intuitive feel to make for a package that punches way above its pay grade.
- Keep things simple with a durable 1x MicroSHIFT drivetrain that offers plenty of range along with a clutch-equipped rear derailleur that keeps your ride quiteand your chain on.
- Pair dead-reliable hubs from Formula with our 25-millimeter internal diameter, hookless Stout rims for a wheelset hat-trick: strong, light and durable.
Specification
Frameset
- Frame
- Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
- Seat Binder
- Alloy, quick release, 34.9
Suspension
- Fork
- SR Suntour XCM 29, 30mm Stanchions, Rx Tune, coil spring, custom Multi-Circuit damping w/lockout, QR, 90/100mm travel (size-specific), 46mm offset
Brakes
- Front Brake
- SRAM Level, hydraulic disc, 180/160mm
- Rear Brake
- SRAM Level, 2-piston caliper, hydraulic disc, 180mm
Drivetrain
- Shift Levers
- microSHIFT Advent, 9-speed
- Rear Derailleur
- microSHIFT Advent, 1x9 w/ clutch
- Crankset
- Stout 1x, forged alloy
- Bottom Bracket
- Square-tapered, 73mm, internal bearings, 122.5mm spindle
- Chain
- KMC X9EPT, 9-speed, anti-corrosion coating w/ reusable Missing Link
- Cassette
- microSHIFT Advent, 9-speed, 11-42t
Wheels & tires
- Rims
- Stout Alloy, hookless, double-wall, 25mm inner width
- Spokes
- Stainless, 14g
- Inner Tubes
- Presta, 40mm valve
- Rear Hub
- Formula DC-22, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
- Front Hub
- Formula DC-20, 6-Bolt, disc, 100x9mm spacing, quick-release
- Front Tire
- Fast Trak Sport, 29x2.35"
- Rear Tire
- Fast Trak Sport, 29x2.35"
Cockpit
- Stem
- 3D-forged alloy, 31.8mm, 7-degree rise
- Handlebars
- Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
- Grips
- Specialized MTB Grip, lock-on
- SeatPost
- Alloy, 2-bolt clamp, 30.9mm
- Saddle
- Bridge Sport, Steel rails, 155/143mm
Accessories
- Pedals
- Specialized Flat Pedal
Geometry
| SM | MD | LG | XL | 2XL | |
| Crank Length | 170 | 170 | 175 | 175 | 175 |
| Handlebar Width | 720 | 740 | 740 | 740 | 740 |
| Stem Length | 40 | 60 | 60 | 70 | 70 |
| Saddle Width | 155 | 143 | 143 | 143 | 143 |
| Seatpost Length | 350 | 400 | 400 | 400 | 400 |
| Front-Center | 672 | 696 | 719 | 745 | 770 |
| Reach | 405 | 425 | 445 | 465 | 485 |
| Chain-Stay Length | 440 | 440 | 440 | 440 | 440 |
| Seat-Tube Length | 360 | 400 | 450 | 500 | 560 |
| Stack | 607 | 616 | 626 | 640 | 654 |
| Fork Rake/Offset | 46 | 46 | 46 | 46 | 46 |
| Bike Stand-Over Height | 732 | 754 | 781 | 820 | 853 |
| Head-Tube Length | 95 | 95 | 105 | 120 | 135 |
| Top-Tube Length (horizontal) | 608 | 630 | 654 | 679 | 586 |
| Seat-Tube Angle | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Head-Tube Angle | 68.5 | 68.5 | 68.5 | 68.5 | 68.5 |
| B-B Drop | 62 | 62 | 62 | 62 | 62 |
| Fork Length (full) | 505 | 515 | 515 | 515 | 515 |
| Wheelbase | 1105 | 1128 | 1152 | 1178 | 1203 |
| B-B Height | 310 | 310 | 310 | 310 | 310 |
| Trail | 97 | 97 | 97 | 97 | 97 |
Size
| SM | MD | LG | XL | 2XL |
| 158-165cm | 165-178cm | 175-185cm | 183-196cm | 193-206cm |
