Home Kids/Youth' Bike Youth Bike
Rampage 24" 2025

Rampage 24" 2025

$ 50.24

$ 200.96

Unavailable
Rampage 24" 2025

Rampage 24" 2025

$ 50.24

$ 200.96

Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

The second generation Youth Rampage is purpose-built for big air, taking inspiration from two decades of riding and building dirt jumpers with a light but strong frame and balanced, agile geometry for young riders finding their flow.

Specification
FRAMEAluminum DJ 24"
FORKRST Dirt ,80 mm, 9x100mm
HEADSETTapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40)
GRIPSNorco JR Single lock on, 115mm length
HANDLE BARNorco 6061 alloy, 680mm, 30mm rise
STEMNorco, 40mm Length, 31.8 Clamp
SEAT POSTNorco Pivotal, 27.2mm ID, 200mm Length
SADDLENorco Pivotal
FRONT BRAKETektro MD-280, Mechanical, Resin pads
FRONT BRAKE ROTORTR 160-24, 160mm , 6 bolt
REAR BRAKETektro MD-286, Hydraulic, Resin pads
REAR BRAKE ROTORTR 160-24, 160mm , 6 bolt
BRAKE LEVERSTektro Alloy
CASSETTESingle Speed, 14T
CHAINKMC Z1 natural black 1/2 x 3/32" single speed chain
CRANKSETProwheel 3pc, 30T, 140mm
BOTTOM BRACKETSquare Taper, 73mm, 122.5mm axle
FRONT HUBKT sealed bearing, 3/8" nutted axle, 32H, 6 bolt
REAR HUBKT sealed bearing, 10x135mm, 32H, Single Speed, 14T, 6 bolt
SPOKES/NIPPLESStainless Steel, 14g
RIMSAlex MUS 30, 32h, F/R-24", 23.5mm ID
FRONT TIREKenda K-Rad, 24x2.30", Wire Bead
REAR TIREKenda K-Rad, 24x2.30", Wire Bead
Geometry
Travel (mm front)
80
Reach
375
Stack
524
HTAHead Tube Angle
68.5
OSFork Offset
40
STSeat Tube Length
290
STAEffective Seat Tube Angle
75
RCRear Centre Length
353
BBBottom Bracket Drop
15
BBHBottom Bracket Height
298
HTTHorizontal Top Tube
515
WBWheelbase
971
SOHStandover
559
HTHead Tube Length
100
Trail
80
Maximum Post Insertion
236
Stem Length
35
Crank Length
140
Tire Size
2.35" 2.5"
Size
