Description
The Rampage 2 is purpose-built for big air, taking inspiration from two decades of riding and building dirt jumpers with a light but strong frame and balanced, agile geometry for finding your flow.
Specification
| FRAME | Aluminum DJ 26" |
| FORK | RST Dirt ,100 mm, 9x100mm |
| CRANKSET | Prowheel Forged 3pc, 30T, 165mm |
| BOTTOM BRACKET | Sealed Cartridge, ISIS 73mm |
| CASSETTE | Single speed, 14T |
| CHAIN | KMC Z1, 1/2 x 3/32" |
| FRONT BRAKE | Tektro MD-280, Mechanical, Resin pads |
| FRONT BRAKE ROTOR | TR 160-24, 160mm , 6 bolt |
| REAR BRAKE | Tektro MD-280, Mechanical, Resin pads |
| REAR BRAKE ROTOR | TR 160-24, 160mm , 6 bolt |
| BRAKE LEVERS | Tektro Alloy |
| HANDLEBAR | Norco Alloy, 760mm, 45mm rise |
| STEM | Norco, 45mm Length, 31.8 Clamp |
| SEATPOST | Integrated w/saddle, 27.2mm ID, 200mm Length |
| HEADSET | Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40) |
| HEADSET SPACER | 2x10mm , 1 x 5mm |
| SADDLE | Norco One Piece |
| GRIPS | Norco w/small flange, 130mm length |
| PEDALS | FP 870ZP resin BMX flat pedal with metal pins |
| SEATPOST CLAMP | Norco Alloy QR, 31.8mm ID |
| FRONT HUB | KT sealed bearing, 3/8" nutted axle, 32H, 6 bolt |
| REAR HUB | KT sealed bearing, 3/8" nutted axle, 32H, 14T SS sproket, 6 bolt |
| RIMS | Alex MUS 30, 32h, F/R-26" |
| FRONT TIRE | Kenda K-Rad, 26x2.30", Wire Bead |
| REAR TIRE | Kenda K-Rad, 26x2.30", Wire Bead |
| SPOKES/NIPPLES | Stainless Steel, 14g |
| WEIGHT | 13.29 kg (29.25 lbs) (MD) |
Geometry
| Short | Medium | Long |
|---|---|---|
| 26" | 26" | 26" |
| Travel (mm front) | ||
100 | ||
| Reach | ||
| 405 | 435 | 465 |
| Stack | ||
| 554 | 564 | 573 |
| HTAHead Tube Angle | ||
68.5 | ||
| OSFork Offset | ||
40 | ||
| STSeat Tube Length | ||
300 | ||
| STAEffective Seat Tube Angle | ||
75 | ||
| RCRear Centre Length | ||
379 | ||
| BBBottom Bracket Drop | ||
20 | ||
| BBHBottom Bracket Height | ||
328 | ||
| HTTHorizontal Top Tube | ||
| 554 | 586 | 619 |
| WBWheelbase | ||
| 1037 | 1071 | 1104 |
| SOHStandover | ||
599 | ||
| HTHead Tube Length | ||
| 105 | 115 | 125 |
| Trail | ||
94 | ||
| Maximum Post Insertion | ||
245 | ||
| Stem Length | ||
35 | ||
| Crank Length | ||
165 | ||
| Tire Size | ||
2.35" 2.5" | ||
