Home Mountain Bikes All
One Sixty 7000 2025

One Sixty 7000 2025

$ 58.23

$ 232.92

Unavailable
One Sixty 7000 2025

One Sixty 7000 2025

$ 58.23

$ 232.92

Size:
  • SH
  • MD
  • LG
  • XL
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

Taking the tested and award-winning full carbon frame that won Bikeradar's Enduro Bike of the Year 2023 and pairing it with the latest high-end Marzocchi fork brings top level performance to any enduro track. Add to this the ability to run 29" or mixed 29"/27.5" wheels, our proven FAST kinematics plus the perfect mix of components from Shimano and Race Face and you have a race winning combination.

Evolution or revolution? How about both? The ONE-SIXTY is a radical, award-winning design that pushes our hard-hitting enduro platform to new heights. Just as well, because once its there its ready to rip the longest, toughest descents too. Our proven suspension system uses a flexstay design with an adjustable rocker, so whether you choose to run it as a full 29er (162 mm travel) or mixed 29/27.5 setup (171 mm travel), the geometry is preserved. Theres a radically steep 79 seat tube angle for goat-like climbing and slack 64 head angle plus 170 mm fork to deal with downhill trail chaos. Our AGILOMETER sizing allows riders to run a longer or shorter reach frame independently of their height, while suspension becomes more progressive as you size up, all with long-travel dropper posts. WIRE PORT cable routing plus reliable threaded bottom bracket round out the package, while carbon frames offer on-board tool storage and FidLock magnetic bottle cages.

Specification
FRAMEONE-SIXTY CF4 III; 171 STR mullet / 162 STR 29"; MAT carbon; 29x2.5" max. WHS; 148x12 AST; BSA BBR
SHOCKMarzocchi Bomber Air; platform
FORKMarzocchi SuperZ; Air; 170 STR; Tapered; 44mm fork offset; 29x2.6" max. WHS
BRAKE-FShimano XT M8120; 4 piston
BRAKE-RShimano XT M8120; 4 piston
ROTOR-FShimano RT64; 203 mm
ROTOR-RShimano RT64; 203 mm
CHAINKMC X12
CHAINGUARDMERIDA EXPERT TR ISCG05
CRANKSETRace Face Turbine; 32 ATC
CRANK LENGTH170 mm for all sizes
BOTTOM BRACKETBB, BSA 73mm ?30mm, Ext. Seal
DERAILLEUR-FRONT
DERAILLEUR-REARShimano XT M8100; SGS
CASSETTEShimano XT M8100; 10-51 ATC; 12 GER
GRIPSMERIDA EXPERT EC
HANDLEBARMERIDA EXPERT TR II; MAT aluminium; 780 WHB; XS/S 18 RHB; M/L/XL 30 RHB
STEMMERIDA EXPERT eTRII; MAT aluminium; 35 DSH; 0 ASD
STEM SIZE40 mm
HEADSETAcros ICR MERIDA INTEGRATED neck; Upper and lower IPS sealing
HUB-FShimano TC500-B; 110x15 WHF; 32 SPH; Centerlock
HUB-RShimano TC600-MS-B; 148x12 WHR; 32 SPH; Centerlock
AXLE-F
AXLE-RMERIDA EXPERT TR; including removeable lever, 6/4mm allen key
RIMRace Face AR30; 30 IWR; Tubeless ready (tubeless tape and valves not included); rear 27.5" up to Size M / L & XL rear 29"
SADDLEMERIDA COMP SL; 25% recycled material; V-mount; incl. MERIDA minitool
SEAT CLAMPMERIDA EXPERT
SEATPOSTMERIDA TEAM TR II; 34.9 DSP; 0 SSB; all sizes 30-230 SPT
SHIFTER-FRONTShimano SL-MT500-IL
SHIFTER-REARShimano XT M8100; Multi Release
SPOKESDouble Butted Black stainless
TIRE-FMaxxis Assegai; 29x2.5"; fold; TR EXO 3C MaxxGrip
TIRE-RMaxxis DHR II; 27.5x2.4" XS/S/M 29x2.4" L/XL; fold; TR DD 3C MaxxTerra
Geometry

XSSHMDLGXL
Tyre Sizes29/27.5"29/27.5"29/27.5"29"29"
ST seat tube [mm]400410425445470
TT top tube [mm]535562589621653
CS chain stay length [mm]434434434437.5437.5
HTA head tube angle []6464646464
STA seat tube angle []7979797979
BD bottom bracket drop [mm]77777
HT head tube [mm]959595105120
FL fork length [mm]581581581581581
R reach [mm]415442470498525
S stack [mm]615615615625638
WB wheel base [mm]11881215124212751308
SH stand over height [mm]727730737736776
Size
FRAME SIZEBODY HEIGHT
S< 173 cm
M167 - 183 cm
L177 - 190 cm
XL> 187 cm
