MODERN MOUNTAIN BIKE TRAILS ARE FUN, FLOWY AND CHALLENGING. THIS FULL-SUSPENSION 29ER GETS YOU IN SYNC WITH THE TERRAIN, SO YOU CAN RIDE WITH MORE CONFIDENCE AND HAVE MORE FUN.
Features
- Handcrafted with lightweight, stiff and durable ALUXX aluminum, it's the perfect entry to full-suspension performance.
- FlexPoint Suspension technology helps you tackle challenging terrain and improve your trail riding capabilities.
- Larger diameter wheels roll over rugged terrain with balance and stability, giving you the momentum to tackle technical climbs and the confidence to fly on singletrack descents.
Specifications
- Intended Use- Trail
- Wheel Size- 29"
- Braking System- Hydraulic Disc
- Frame Material- Aluminium
Components
- Frame- Aluxx -Grade front and rear triangles, Flexpoint Suspension, 120mm travel, 141mm Boost Quick Release.
- Fork- Crest 34 SL RCL 130mm, 15X110 TA
- Bottom Bracket- SRAM DUB
- Chain- SRAM SX Eagle
- Crank- SRAM SX Eagle DUB, 30t, steel ring, 52mm chainline
- Shift Levers- SRAM SX Eagle 1x12
- Cassette- SRAM SX Eagle 11-50t
- Rear Derailleur- SRAM SX Eagle
- Grips/Bartape- Giant Sole-O Grip
- Handlebar- Giant Connect Trail, 780mm x 31.8mm,GA 690mm
- Stem- Giant Contact
- Saddle- Giant Romero
- Seatpost- Giant Contact Switch dropper post with remote lever\, 30.9mm
- Front Brake- Shimano MT-420 [F] 180 , Hydraulic
- Rear Brake- Shimano MT-420 [R] 160, Hydraulic
- Front Wheel- GIANT AM 29 tubeless ready sleeve-joint rim, 30mm inner width.
- Rear Wheel- GIANT AM 29 tubeless ready sleeve-joint rim, 30mm inner width.
- Tire- [F R] Maxxis Forekaster 2.35", Foldable, 60 TPI, EXO TR, Tubeless tires
- Pedal- Al body/AL cage Platfrom(GC,GT)
Geometry
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Seat Tube Length(mm) | 380 | 431 | 482 | 507 |
| B | Seat Tube Angle | 75 | 75 | 75 | 75 |
| C | Top Tube Length(mm) | 570 | 593 | 624 | 645 |
| D | Head Tube Length(mm) | 100 | 100 | 125 | 140 |
| E | Head Tube Angle | 67.5 | 67.5 | 67.5 | 67.5 |
| F | Fork Rake(mm) | 44 | 44 | 44 | 44 |
| G | Trail(mm) | 100.1 | 100.1 | 100.1 | 100.1 |
| H | Wheelbase(mm) | 1134 | 1157 | 1192 | 1215 |
| I | Chain Stay Length(mm) | 438 | 438 | 438 | 438 |
| J | Bottom Bracket Drop(mm) | 40 | 40 | 40 | 40 |
| K | Stack(mm) | 612 | 612 | 635 | 668 |
| L | Reach(mm) | 406 | 429 | 454 | 471 |
| M | Stand Over Height(mm) | 730 | 734 | 763 | 782 |
| N | Handlebar Width(mm) | 780 | 780 | 780 | 780 |
| O | Stem Length(mm) | 50 | 50 | 50 | 50 |
| P | Crank Length(mm) | 165 | 170 | 170 | 170 |
| Q | Wheel Size | 29 | 29 | 29 | 29 |
Additional Info
- Country of Origin: China
- Imported By: Element Retail Pvt Ltd , Plot No. 18/1/1 , Near Sakal Circle , MIDC , Satpur Colony , Nashik , Maharashtra- 422007 , India.
- Net Quantity: 1N
- Customer Care Address: 291, 10 Main, 5 Block, Jayanagar, Bangalore - 560041. Ph: (080)47183232, Email: [email protected]
- Commodity: Bicycles
