- STRONG AND DYNAMIC SHIMANO EP8 E-DRIVE WITH INTEGRATED, REMOVABLE 720 WH BATTERY
- 150 MM TRAVEL WITH NEW F.O.L.D. KINEMATICS OPTIMIZED FOR MORE PROGRESSION: ROCKSHOX 35 GOLD SUSPENSION FORK AND DELUXE SELECT REAR SHOCK
- LONG SERVICE LIFE AND RELIABLE SHIFTING: SHIMANO SLX GROUPSET AND 4-PISTON BRAKES, PLUS FULLY INTEGRATED C.I.S. CABLE ROUTING FOR A CLEAN LOOK WITH TOP PERFORMANCE
CONQUERS NEW MOUNTAINS
MORE DYNAMIC AND RANGE, BUT LESS WEIGHT
Shimano's EP8 e-drive offers dynamic power and a lightweight system that supports the JAM 7.8's agile geometry. Furthermore, our specially developed, integrated, yet removable battery supports your super long rides with 720 Wh. Additionally, a USB C port on the top tube gives you the opportunity to charge your devices.
OPTIMIZED KINEMATICS FOR STRONG PROGRESSION
With the upgrade of our well-known F.O.L.D. kinematics, your JAM 7.8 is ready to shred even more. We kept the well-liked sensitivity of the F.O.L.D. but changed the positioning of our kinematics within the frame for strong bottom-out resistance. The characteristics are completely progressive which results in a chassis that offers a lot of stability in rough terrain. Especially e-mountain bikes with their additional weight of motor and battery benefit from more progression. This allows you to handle any trail while the chassis still provides comfort for long laps. Furthermore, the lower standover of the JAM 7.8 gives you more space to play on the trail.
MORE FUN ON THE TRAILS
Riding performance first. The JAM 7.8 will make your ride better every time. An agile, nimble geometry in a slim, compact design will push you over all kind of trails whether technical or flow. The FLIP CHIP at your JAM 7.8's linkage can be used to adjust your geometry to an even more aggressive riding style. The small adjustment of the head angle from 65,5 to 65 changes your whole set-up goal making it even more downhill-oriented. Additionally, the specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. On top, all your essentials fit in the tool bag between top and down tube.
| FRAME | 7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. GEN2 kinematics, 148x12 mm thru axle, internal cable routing, USB-C port, post mount 203 mm |
| FRAME MATERIAL | Aluminium |
| FORK | Rock Shox 35 Gold RL 29 Boost, 110x15mm, 44mm rake, 150mm travel |
| TRAVEL FORK | 150 mm |
| SHOCK | Rock Shox Deluxe Select, 210/55 mm, hardware: 25.0 x 8.0 mm, no Bushing |
| MOTOR | Shimano Steps EP8, 36V / 250 W / 85 Nm |
| BATTERY WATT-HOURS | 720 Wh |
| BATTERY AMPERE HOURS | 20,8 Ah |
| DISPLAY | Shimano SC-E5003 |
| SHIFTER | Shimano SLX M7100, 12-speed |
| REAR DERAILLEUR | Shimano SLX M7100, 12-speed |
| SPROCKET | Shimano Deore CS-M6100, 12-speed |
| CHAIN | Shimano CN-LG50 |
| CRANKSET | Samox EC40 ISIS |
| BOTTOM BRACKET | Integrated in Drive Unit |
| TRANSMISSION OF DRIVE | Front: 36T, Rear: 10-51T |
| HANDLEBAR | Aluminium, 800 mm, rise: 30 mm, backsweep: 9 |
| STEM | FOCUS C.I.S. integrated, 50 mm, 0, 35 mm, aluminium |
| HEADSET | ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset |
| SADDLE | FOCUS Race SL |
| SEATPOST | FOCUS Post Moderne dropper post PM-214, 34.9 mm |
| BRAKES | Shimano MT520, hydraulic disc brake |
| BRAKE LEVER | Shimano MT520 |
| BRAKE | Disc |
| RIMS | RaceFace AR30 Offset |
| REAR HUB | Shimano MT410, 12x148 mm |
| FRONT HUB | Shimano MT410, 15x110 mm |
| TIRES | Maxxis Minion DHF, EXO, 63-622 |
| GEARS | 12 |
| BIKE WEIGHT INCL. BATTERY IN KG | 25.0 kg |
| SIZE | S, M, L, XL |
Speed limit for e-support in New Zealand is 32 km/h. Our e-bikes are adjusted accordingly.
* Subject to technical modification without notice. Errors and omissions excepted.
** Weight in size M, of standard specification and without pedals.
