Home Electric Bike
EOne Sixty Lite 675 2024

EOne Sixty Lite 675 2024

$ 53.00

$ 176.48

Unavailable
EOne Sixty Lite 675 2024

EOne Sixty Lite 675 2024

$ 53.00

$ 176.48

Size:
  • LG
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

Say hello to a huge range and ride fun without saying goodbye to your budget. The eONE-SIXTY 675 gets a durable aluminium frame and user-removable 750 Wh battery with an optional 360 Wh range extender, but we combine our award-winning handling and suspension with wallet-friendly kit to give you maximum bang for your buck. A stout Marzocchi Z1 170 mm fork and Bomber Air shock keep trail chaos under control, while the Shimano Deore Linkglide drivetrain is tough enough for e-bike use, day in, day out.

With the new eONE-SIXTY, the next descent is always about to start. With an all-aluminium frame, it offers maximum value and maximum battery range, thanks to a powerful drive unit paired with a removable 750 Wh battery and optional 360 Wh range extender. The only reason to stop will be because you have to. With our incredibly capable geometry derived from the award-winning ONE-SIXTY enduro range, we've got handling that'll help you conquer the toughest climbs as well as the most grin-inducing descents, while our proven FAST kinematic suspension will take care of anything the trail throws at it. This low-maintenance flexstay design offers 174 mm of rear wheel travel to go with 170 mm at the front, with size-tuned progression to maximise performance for all sizes of riders. You can run it with the latest coil shocks without any worries too. With mixed size 29" front and 27.5" rear wheels as standard for playful handling, you can switch to a focussed full 29er setup without messing up the geometry, thanks to our flip chip design. With low standover heights across all sizes, you can choose between a longer frame for more stable handling or a shorter one for an agile feel, while some models feature our ground-breaking 30-230 mm travel-adjustable dropper post.



Specification
FRAME SIZEXShort, Short, Mid, Long, XLong
COLOURSILK FOG GREEN (WHITE)
HEADSETAcros ICR MERIDA EXTERNAL neck w/ Blocklock
GRIPMERIDA EXPERT EC
DERAILLEUR (R)Shimano DEORE M5130 LinkGlide 10
SHIFTERSShimano SL -MT500-IL / Shimano Deore M5130
SEAT CLAMPMERIDA EXPERT
PEDALVP VPE-527
CHAINShimano LG500
SPOKESBlack stainless
LIGHT FRONTLezyne E-Bike Power STVZO E115, reverse MERIDA Custom Mount
LIGHT REARLezyne LED Femto USB STVZO
FENDERC093-02F C093-02R
BATTERYTrendpower Internal Battery 750Wh
DISPLAYShimano SC-EM800



Geometry
FRAME SIZEXSHORTSHORTMIDLONGXLONG
TYRE SIZES29/27.5"29/27.5"29/27.5"29/27.5"29/27.5"
ST SEAT TUBE [MM]400410425445465
TT TOP TUBE [MM]546567589610632
CS CHAIN STAY LENGTH [MM]446446446446446
HTA HEAD TUBE ANGLE []64.464.464.464.464.4
STA SEAT TUBE ANGLE []78.578.578.478.478.3
BD BOTTOM BRACKET DROP [MM]99999
HT HEAD TUBE [MM]100105110115120
FL FORK LENGTH [MM]581581581581581
R REACH [MM]419439459479499
S STACK [MM]624628633637642
WB WHEEL BASE [MM]11991221124412661288
SH STAND OVER HEIGHT [MM]763757751749744


Size
FRAME SIZEBODY HEIGHT
XS< 163 cm
S157 - 173 cm
M167 - 183 cm
L177 - 190 cm
XL> 187 cm
