Demo Race 2025

Demo Race 2025

$ 53.28

$ 213.12

Unavailable
Demo Race 2025

Demo Race 2025

$ 53.28

$ 213.12

Size:
  • S2
  • S3
  • S4
Colour:
  • Obsidian
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Description

All-out speed has always been the Demos target, and with the Demo Race, its no different. Introducing a new flexible wheel-size frame design that allows riders to take advantage of a 29-inch front wheel and a 27.5-inch rear wheel, its a special blend thats long been tested by World Champ Loc Bruni looking for the perfect balance of traction and maneuverability, but only just green-lighted by the UCI this past year. Not that it stopped the Demo Race from racking up both the Downhill World Championship and overall World Cup titles in its very first season...

Now, were offering that same winning combination straight out of the box, while an adjustable rear end that still allows you to change between 27.5 and 29-inch wheel sizes based on terrain and riding style while also adjusting for proper chainstay length and bottom bracket height.

Blazing fast on tough tracks, the Demo Race suspension design has been developed around a more rearward axle path that reduces rear-wheel hang-up, increasing speed instead.

Top-shelf suspension from hlins takes advantage of the most proven suspension kinematics on the World Cup circuit, and SRAMs DH-specific X01 drivetrain has you covered from the start gate to finish line.

  • The Demo Race M5 alloy frame is fully optimized to take advantage of the traction benefits of a 29-inch front wheel and the increased manueverability of a 27.5-inch rear wheel while maintaiining the ability to change your rear wheel size to suit different terrain and riding styles with an adjustable rear end that ensures chainstay length and bottom-bracket height stay dialed no matter the hoop size.
  • The hlins TTX22M.2 coil shock is designed to handle the most challenging World Cup Downhill tracks, offering external low speed compression and rebound adjustment while the Trunnion mount offers extra bushing overlap for increased durability.
  • With superb small bump tracking and the ability to soak up landings from even the heftiest drop-off, the hlins DH38 m.1 forks 200-millimeters of travel will give you smoother, faster, and more confident feeling runs than anything youve ridden before.
    Specification
    Cockpit
    Saddle
    Body Geometry Henge DH, hollow titanium rails, 130mm
    Grips
    Deity Lockjaw
    Handlebars
    Renthal Fatbar 35, 5-degree upsweep, 7-degree backsweep, 30mm rise, 800mm, 35.0mm
    Stem
    Renthal Integra 35mm Direct Mount Stem, 45mm length
    SeatPost
    Thomson, alloy, straight, 12-degree clamp
    Frameset
    Frame
    M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
    Seat Binder
    Alloy, 34.9mm
    Suspension
    Fork
    hlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel
    Rear Shock
    hlins TTX22M.2 Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75
    Brakes
    Front Brake
    SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 220mm
    Rear Brake
    SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 200mm
    Drivetrain
    Bottom Bracket
    SRAM DUB, 83mm
    Cassette
    SRAM X01 DH, 7-speed, 10-24t
    Rear Derailleur
    SRAM X01 DH, 7-speed, trigger
    Crankset
    SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
    Shift Levers
    SRAM X01 DH, trigger, 7-speed
    Chain
    Sram PC1130 w/ Powerlink, 11-speed
    Wheels & tires
    Rims
    Roval Traverse Alloy 29" / 27.5", 32h alloy rim, 28mm inner rim width
    Front Hub
    DT Swiss 350 hub, 20x110mm
    Front Tire
    Cannibal, GRID GRAVITY casing, GRIPTON T9 compound, 2Bliss Ready, 29x2.3"
    Rear Tire
    Cannibal, GRID GRAVITY casing, GRIPTON T9 compound, 2Bliss Ready, 27.5x2.3"
    Rear Hub
    DT Swiss 350 hub, 12x148mm
    Spokes
    Sapim D-Light
    Inner Tubes
    Standard, Presta


    Geometry

    S2S3S4
    Chain-Stay Length (29)448448448
    B-B Drop252525
    Front-Center (27.5 mid)801821841
    Stack632632632
    Head-Tube Angle62.862.862.8
    Head-Tube Angle (27.5 mid)62.562.562.5
    Stack (27.5 mid)635635635
    Reach426446466
    Wheelbase (mid)124412641284
    Seat-Tube Length394420420
    Seat-Tube Angle78.276.876.8
    Seat-Tube Angle (29 mid)78.577.177.1
    Stack (29 mid)629629629
    Head-Tube Angle (29 mid)63.263.263.2
    B-B Height (29 mid)355355355
    Chain-Stay Length (mid)443443443
    Wheelbase (27.5)123912591279
    Fork Rake/Offset565656
    Chain-Stay Length (27.5)438438438
    Trail (27.5 mid)132132132
    Front-Center801821841
    Reach (29 mid)430450470
    Reach (27.5 mid)423443463
    B-B Height350350350
    Trail (29 mid)127127127
    Seat-Tube Angle (27.5 mid)77.876.476.4
    Trail130130130
    Front-Center (29 mid)801821841
    Head-Tube Length105105105
    B-B Height (27.5 mid)345345345
    Wheelbase (29)124912691289
